Lift Height

Capacity

Engine

Capacity Weight

max

Maximum Height

Forward Reach

12,000 lbs

Bed Capacity

two capacity
5,000 lbs

Tow Capacity

21 ft 3 in

Bed Length

Dove Tail Capacity

Cummins 15L Engine

Minumum Height

Inside Ramp Width

Max Lift Height

EZ12

Model

  • Bulkhead bolted to the frame
  • Traction plate full ramp
  • Knife edge ramp
  • Chain tie-downs (every 1′ 2″ to 1′ 10″)
  • Dock loading ability
  • Nylon strap tie-downs
  • Positive tail lock (non hydraulic)

NOTE: Customer to provide chassis. Capacity rating for bed only, vehicle capacity rating dependent on final configuration of chassis, options installed, road regulations, and drivetrain specifications.

Bed Capacity
12,000 lbs
Dove Tail Lift Capacity
8,000 lbs
Tow Capacity
5,000 lbs
Approximate G.V.W.
26,000 lbs
Hydraulic Pump P.T.O.
14 gal
Overall Bed Dimensions
8 ft 6 in W x 21 ft 3 in L
Main Bed Dimensions
8 ft 6 in W x 13 ft 5 in L
Dove Tail Dimensions
8 ft 6 in W x 7 ft 5 in L
Flip Tail Dimensions
8 ft 6 in W x 4 ft 7 in L
Bulk Head Height
5 ft
Cab to Axle (C.A.)
11 ft 6 in
Ramp Length
11 ft 11 in
Bed Height (Ground)
3 ft 5 in
Maximum Dock Height
5 ft 5 in
Ramp Degree/Percent
18° / 32%
Hitch Receiver Tube
2 in
Wood Thickness
1 in
Minimum chassis frame rail height
38 in
1/4″ Aluminum Diamond Plate (Bulk Head Cover)
4′ Tool Box Each – EZ12, EZ18, EZ24
Emergency Loading Light Bar 5′
2 Way “Winch Only” Operation (Corded Pendant)
Custom Paint*
6’tool Box Each – EZ12, EZ18, EZ24
8′ Tool Box Each – EZ24
Loading Lights (LED) Each
Hydraulic Winch (10,000 lbs Capacity) – Weight 150 lbs**
Hydraulic Winch (15,000 lbs Capacity) – Weight 200 lbs***
2 Way “Winch Only” Operation (Wireless Radio Remote)
6 Way “Winch & Bed” Operation (Corded Pendant)
6 Way “Winch & Bed” Operation (Wireless Radio Remote)
PTO w/Pump–Electric (Most Common)

* Standard bed colors include white/black/gray/XMFG orange.
** 10,000 lb winch option pricing includes tension/level winder & 75′ cable with hook.
*** 15,000 lb winch option pricing includes tension/level winder & 100′ cable with hook.

Specifications are subject to change without notice. Photos and diagrams on this website and within downloadable materials are for promotional purposes only. Refer to the appropriate Xtreme Manufacturing operation manual for detailed instructions on proper use, specifications and maintenance of equipment.
