Lift Height

12,000 lbs

Capacity

Engine

max

Maximum Height

Capacity Weight

31 ft 6 in

Forward Reach

Bed Capacity

two capacity

Tow Capacity

Bed Length

Dove Tail Capacity

Cummins 15L Engine

Minumum Height

Inside Ramp Width

47 ft

Max Lift Height

XR1247-B

Model

  • 360° operator visibility
  • Ductile steel manifold
  • Suspension seat
  • Easy cab mounted grab handles
  • Easy service access
  • Master disconnect switch
  • Protected tilt & extend cylinders
  • Boom lift point
  • Steel hydraulic & fuel tanks
  • Manual lowering valve (cylinders)
  • Long life Lexan labels
  • Large cross section boom
  • Heavy duty boom chains
  • Easy tie downs
  • Suspended pedals ˝Y˝ frame handle
  • Large capacity fuel tank
  • Heavy duty pre-cleaner
  • Trunnion mounted sway cylinders
  • Additional high pressure hydraulic filter
  • Melonite pins Individual gauges/switches
  • Standard auxiliary hydraulics
  • Steel hood
  • Steel dash
  • Solid steel plate chassis
  • Center mounted powertrain
  • Rear axle stabilization (RAS)
  • Long life boom rollers
  • Wider outrigger stance
  • Dual batteries
  • Back up alarm with light
  • Cab step
  • Electrical aux hydraulic control
Class Carriage
B
Capacity Weight
12,000 lbs
Lift Height
47 ft
Forward Reach
31 ft 6 in
Frame Leveling L/R
11 degrees
Machine Weight
37,200 lbs
Engine
Cummins 3.8L 120 hp (Tier 4F)
Axles
Dana 213
Transmission
Dana T20000
Fuel Capacity
50 gal
Tires
Foam Filled 15.5 x 25
Hydraulic Flow (per min)
49 gal
Hydraulic Pressure
3,500 psi
Hydraulic Oil Capacity
62 gal
Length to fork face
21 ft 3 in
Width
101 in
Height
8 ft 1 in
Wheel Base
125 in
Ground Clearance
16.5 in
Turning Radius
12 ft
Outriggers
Yes
Enclosed Cab W/ Heat
Enclosed Cab W/ Heat & Ac
Open Cab
ADJ Carriage 48″ (Fork Positioning)
Fixed Carriage 48″
Fixed Carriage 60″
Fixed Carriage 72″
Fixed Carriage 96″
Swing Carriage 72″
Swing Carriage 52″
ADJ Carriage 60″ (Fork Positioning)
ADJ Carriage 72″ (Fork Positioning)
Side Shift Carriage 50″
Side Tilt 48″
Side Tilt 52″
Side Tilt 72″
Carriage Fork 3 X 2.00 X 48
Carriage Fork 4 X 2.25 X 42
Carriage Fork 4 X 2.25 X 48
Carriage Fork 4 X 2.25 X 60
Carriage Fork 5 X 2.25 X 48
Carriage Fork 6 X 2.50 X 72
Carriage Fork 5 X 2.25 X 60
Carriage Fork 6 X 2.00 X 120
Carriage Fork 6 X 2.00 X 144
Carriage Fork 6 X 2.00 X 72
Carriage Fork 6 X 2.00 X 96
Carriage Fork 6 X 2.75 X 96
Carriage Fork 7 X 1.75 X 48
Carriage Fork 7 X 1.75 X 60
Carriage Fork 7 X 2.25 X 60
Carriage Fork 7 X 2.25 X 72
Carriage Fork 7 X 2.25 X 96
Carriage Fork 6 X 2.00 X 48 Full Taper DW
Carriage Fork 5 X 2.25 X 48 Full Taper
Carriage Fork 6 X 2.25 X 48 Full Taper
Block Fork 2 X 2 X 48
Block Fork 2 X 2 X 42
Carriage Fork 6 X 2 X 96 Full Taper
Foam Filled Tires 15.5 X 25 G2
Foam Filled Tires 15.5 X 25 E3
Solid Tires 14 X 24
Battery Blanket
Boom Maintenance Stand
Boom Work Lights-LED
Cold Weather Synthetic Oil
Custom Decal Setup
Enclosed Cab Clear Glass
Flashing Amber Beacon (Strobe)
Flashing Green Strobe
Fuel Cap Locking
Hydraulic Tank Heater
Machine Lifting Points
Rear Cab Work Lights-LED
Rear Camera Option
Rotating Amber Beacon
Special Paint (Excluding The Cab)
Special Paint (Including The Cab)
Swivel Hook
Steel Fender Option
Tail/Turn Lights W/Strobe
Cab Heater-Auxilliary
Tail/Turn Lights W/o Strobe
KIT, LMI Dovertwg
Coordinated Motion
Breather Heater/High Idle
Cable Reel
Pintle Hook
Dual Batteries
Top Curved Glass
White Noise Backup Alarm
Sling Mount
Truss Boom 12′ (Star)
Truss Boom 15′ (Star)
Truss Boom 2′ (Star)
Table Truss Boom
Bucket 1.00 Yd 60″
Bucket 1.00 Yd 72″
Bucket 1.65 Yd Cutting Edge
Pole Grapple 7260 Custom W/Shoe
Skid Steer Adapter
Bucket 1.65 Yd
Bucket 2.00 Yd
Personnel Platform 4′ X 9.97′
Personnel Platform 4′ X 6′
Bucket 1.25 Yd
Personnel Platform 4′ X 4′
Personnel Platform 4′ X 8′
Truss Boom W/ Winch 3′ (Bradco)
Truss Boom W/ Winch 12′ (Bradco)
Pole Grapple 7260
24″ Debris Rake
No Accessory Products found.

Specifications are subject to change without notice. Photos and diagrams on this website and within downloadable materials are for promotional purposes only. Refer to the appropriate Xtreme Manufacturing operation manual for detailed instructions on proper use, specifications and maintenance of equipment.
